Once the adjustment is completed, check the correct
value (B) of uniball travel (3).
The uniball (3) travel value (B) must be between 0 mm
(0 in) (uniball completely screwed in) and 6 mm (0.24
in).
Warning
If the travel value does not respect the indicated
parameters, repeat the adjustment operations as
described before.
Fig. 198
Fig. 199
244
