Rear brake pedal
Loosen lock nut (7).
Turn pedal stroke adjusting screw (6) until pedal is in
the desired position. Tighten the lock nut (7).
Operate the pedal (8) by hand to check that there is 1.5
to 2 mm (0.06÷0.09 in) of free play before the brake
bites.
If not, adjust the length of the master cylinder
pushrod.
Warning
Have the pedal adjusted at a Ducati Dealer or
authorised Service Centre.
Fig. 200
Fig. 201
245
