Ducati PANIGALE V4 - Page 281

Slide out the ignition switch cover (4) from the rear
and from upwards, paying attention to the inner tabs
(A) connected to the side fairing, positioned on both
sides.
Loosen screw (11) and slide out cover (12) retaining
the battery.
4
A
Fig. 230
1112
Fig. 231
280
