Slide out the battery (6) from its housing and, always
starting from the negative terminal (-), loosen the
screws (7).
Remove the ABS positive cable (8) and positive cable
(9) from the positive terminal and the two negative
cables (10) from the negative terminal.
Warning
The battery produces explosive gases: keep it
away from sparks, flames, cigarettes and heat
sources.
Warning
Keep the battery out of the reach of children.
Charging the battery
Charge the battery in a duly ventilated room with a
temperature below 40° C (104° F).
Connect the battery charger leads to the battery
terminals, respecting polarity: the red one to the
positive terminal (+), the black one to the negative
terminal (-).
Warning
Before activating the battery charger, connect it
to the battery always starting with the red positive
terminal (+) first.
Warning
While charging, the battery gives off toxic
gases. Recharge in a ventilated room.
Fig. 232
281
