Refitting
Lay down the ABS positive cable (8), onto positive
cable (9) and start screw (4) on these cables.
Connect the two negative cables (10) to battery
negative terminal, by starting the other screw (4).
Tighten the terminal screws (4) to a torque of 2Nm
and apply grease onto the battery terminals to
prevent oxidation.
Reinstall the battery (6) in the support, positioning the
cables as shown in (Fig. 233).
Position the cover (12) fastening the battery and
tighten the screw (11).
Fig. 233
Fig. 234
282
