Settings via the software
Operating Instructions 878-M PREMIUM - 02.0 - 02/2018 83
4. Select another program number using / or input a program
number using the keypad keys 0 - 9 and then press OK.
The following information is shown on the display,
the P in the program number field flashes:
Fig. 57: Programming display
5. Press the upper softkey.
The following table shows the individual symbols on the display
and the functions of the keys on the control panel.
Symbol Meaning
Auto Forward
Value range: on/off
Add section
Delete section
Number of current program to be created
No function assigned
Current section
•Use
/ to select the Section parameter.
•Use
/to switch to the next/previous section.
• Press the OK key to edit other parameters for the
section,
8.6.4 Editing programs, str. 86.
Stitch length for the current section
Value range: 0.0 to 7.0 mm
•Use
/ to select the Stitch length parameter.
•Use
/ to change the stitch length.
