Dynapac CC722 - Dimensions, Top View

Technical specifications
4812158801_E.pdf2018-04-03
Dimensions, top view
Dimensions mm inDimensions mm in
B Width, front 2430 96B Width, front 2430 96
O
1
Overhang, left 112 4,5O
1
Overhang, left 112 4,5
O
2
Overhang, right 112 4,5O
2
Overhang, right 112 4,5
R
1
Turning radius, external 8080 318R
1
Turning radius, external 8080 318
R
2
Turning radius, inner 5950 234R
2
Turning radius, inner 5950 234
W
1
Width Platform, rear 2354 93W
1
Width Platform, rear 2354 93
W
1
Width Cab, rear 2428 96W
1
Width Cab, rear 2428 96
W
2
Drum width 2130 84W
2
Drum width 2130 84
