Machine description

4812158801_E.pdf 2018-04-03

Function description of instruments and

controls in the cab

No Designation Symbol FunctionNo Designation Symbol Function

1 Front working lights, switch Press to switch on the front working lights.1 Front working lights, switch Press to switch on the front working lights.

2 Rear working lights, switch Press to switch on the rear working lights.2 Rear working lights, switch Press to switch on the rear working lights.

3 Windshield washer, switch Press to wash the windshield.3 Windshield washer, switch Press to wash the windshield.

4 Front wiper, switch Press to operate the front screen wiper.4 Front wiper, switch Press to operate the front screen wiper.

5 Blower fan, switch Press to operate the blower fan.5 Blower fan, switch Press to operate the blower fan.

6 Left side window washer, switch Press to wash the left side window.6 Left side window washer, switch Press to wash the left side window.

7 Left side window wiper, switch Press to operate the left side window wiper.7 Left side window wiper, switch Press to operate the left side window wiper.

8 Fuseboxes Contain fuses for the electrical system in the cab.8 Fuseboxes Contain fuses for the electrical system in the cab.

9 Right side window wiper, switch Press to operate the right side window wiper.9 Right side window wiper, switch Press to operate the right side window wiper.

10 Right side window washer, switch Press to wash the right side window.10 Right side window washer, switch Press to wash the right side window.

11 Heater control Turn to the right to increase heating.

Turn to the left to reduce heating.

11 Heater control Turn to the right to increase heating.

Turn to the left to reduce heating.
