Dynapac CC722 User Manual

Maintenance - Lubricants and symbols
4812158801_E.pdf 2018-04-03
Articulated joint SKF LGHB2 (NLGI
Class 2)
Articulated joint SKF LGHB2 (NLGI
Class 2)
FUEL See engine manual. - -FUEL See engine manual. - -
TRANSMISSION OIL Air temperature -15°C - +40°C
(5°F-104°F)
Dynapac Gear oil 300,
P/N 4812030756 (5 litres),
P/N 4812030117 (20 litres),
P/N 4812031574 (209
litres)
TRANSMISSION OIL Air temperature -15°C - +40°C
(5°F-104°F)
Dynapac Gear oil 300,
P/N 4812030756 (5 litres),
P/N 4812030117 (20 litres),
P/N 4812031574 (209
litres)
Air temperature 0°C (32°F) -
above +40°C (104°F)
Shell Spirax S3 AX
85W/140, API GL-5
Air temperature 0°C (32°F) -
above +40°C (104°F)
Shell Spirax S3 AX
85W/140, API GL-5
COOLANT Anti-freeze protection down to
about -37°C (-34.6°F)
GlycoShell/Carcoolant
774C (mixed 50/50 with
water)
COOLANT Anti-freeze protection down to
about -37°C (-34.6°F)
GlycoShell/Carcoolant
774C (mixed 50/50 with
water)
Maintenance symbols
Engine, oil level Air filterEngine, oil level Air filter
Engine, oil filter BatteryEngine, oil filter Battery
Hydraulic reservoir, level SprinklerHydraulic reservoir, level Sprinkler
Hydraulic fluid, filter Sprinkler waterHydraulic fluid, filter Sprinkler water
Drum, oil level RecyclingDrum, oil level Recycling
Lubricating oil Fuel filterLubricating oil Fuel filter
Coolant level Pump gear, oil levelCoolant level Pump gear, oil level
62
