Towing short distances when the engine is
inoperative
Fig. Pump for releasing the brake
1. Handle for activating the brake
2. Pump lever
1
2
Chock the drums to prevent the roller moving
when the brakes are mechanically disengaged.
Chock the drums to prevent the roller moving
when the brakes are mechanically disengaged.
Set a steel bar in the pump lever (2) and pump by
moving the bar up and down until the brakes release
or until a certain amount of hydraulic resistance can be
felt.
The brakes are now disengaged and the roller can be
towed at LOW speed.
After towing. Pull the lever (1) to activate the brake.After towing. Pull the lever (1) to activate the brake.
Always lock the pump with a padlock when it is
not in use.
Always lock the pump with a padlock when it is
not in use.
