Model 200i and 250i Motorcycle Dynamometer Installation Guide

CHAPTER 2

Support Arm and Monitor Tray

2-22

Figure 2-22: Install the Support Arm and Monitor Tray

MA017

second arm

poly washer

first arm

monitor tray

support arm

poly washer
