INSTALLATION
Tire Carriage Installation
Version 5 Model 200i and 250i Motorcycle Dynamometer Installation Guide
2-35
4 Remove the four 1/4 x 20-inch button-head screws securing the bearing bracket.
5 Remove the bearing bracket and the carriage screw.
Figure 2-36: Remove the Bearing Bracket and Carriage Screw
screw
bearing
bracket
carriage
screw
