CHAPTER 2
Side and T
op Cover Installation
Above Ground Model 250i Mot
orc
ycle Dynamometer Inst
alla
tion Guide
2-44
6
Secure the eddy curre
nt brake top cover with the scre
ws you removed earlier.
Figure 2
-40: Replace the Eddy Current Brake T
op Cover
EB242
eddy current
brake cover
69
71
