Model 200i and 250i Motorcycle Dynamometer Installation Guide
CHAPTER 3
Remove and Replace Dyno and Drum Covers
3-6
4 Remove the two 5/16-inch bolts and washers securing each of the carriage clamps
and shims and set aside.
5 Remove the three carriage clamps and shims and set aside.
6 Remove the two 5/16-inch bolts and washers securing the nut block and shim and
set aside.
7 Remove the nut block and shim and set aside.
8 Remove the six 1/4-20 x 5/8-inch pan head screws securing the center panel to the
dyno carriage and set aside.
9 Remove the center panel and set aside.
Figure 3-5: Remove the Center Panel
MC124
screw
center panel
carriage clamp
washer
bolt
shim
nut block
shim
