User’s Manual xLogic SuperRelay
xLogicSoft solution
The xLogic system can replace the automatic stairway light switch or the pulse relay.
xLogic also lets you create a simple automatic stairway light switch via the stairway light
switch SFB.
You can also implement both functions (off delay timer and pulse relay) in a single unit.
What is more, you can incorporate extra functions without making any alterations to the
wiring. In our example program, we have combined the advantages of both the current
impulse relay and the automatic stairway lighting timer as follows:
Actuate the pushbutton The light is switched on and switched off again on
expiration of a predefined time.
Hold the pushbutton down Switches on continuous lighting
Press the pushbutton once more Switches off the lighting
