User’s Manual xLogic SuperRelay
Appendix
A Technical data
A.1 General technical data
Criterion Tested in accordance
with
Values
ELC-18 Series Main
Module
Dimensions
(W x H x D)
Weight
Installation
95 x 90 x 55 mm
Approx. 200 g
on a 35 mm profile rail or
wall mounting
ELC-12 Series Main
Module
Dimensions
(W x H x D)
Weight
Installation
72 x 90 x 53 mm
Apporox.170g
on a 35 mm profile rail or
wall mounting
ELC-E-16 Series
Expansion Module
Dimensions
(W x H x D)
Weight
Installation
72 x 90 x 53 mm
Apporox.150g
on a 35 mm profile rail or
wall mounting
Climatic conditions
Ambient temperature
Horizontal installation
Vertical installation
Storage/shipping
Low temperature to
- -
IEC 6006821
High temperature to
IEC 60068-2-2
0 ... 55 °C
0 ... 55 °C
-40 °C ... +70 °C
Relative humidity IEC 60068-2-30 From 10 to 95 % no
condensation
Air pressure 795 ... 1080 hPa
Pollutants IEC 60068-2-42
IEC 60068-2-43
SO
2
10 cm
/m
,
4 days
H2S 1 cm
3
/m
3
,
4 days
