xLogic SuperRelay User’s Manual
15
Connecting the PC cable to the USB port
If your PC is only equipped with a USB interface (Universal Serial Bus), you will need a
ELC-USB module to connect the xLogic cable to this port. For the ELC-USB module
information, refer to Chapter 1.
Closing the communication mode
When the data transfer is completed, the connection to the PC is shut down automatically.
Note
If the circuit program created with xLogic is password protected, both the circuit program
and the password are downloaded to xLogic. The password prompt is enabled at the end
of the data transfer. The upload of a password protected program created in xLogic is only
possible after the correct password is entered in
xLogic.
