6. xLogic Software
xLogic soft is available as a programming package for the PC. This software
provides many features, for example:
 A graphic interface for offline creation of your circuit program by means of
Function Block Diagram (function chart)
 Simulation of your circuit program on the PC
 Generating and printing of an overview chart for the circuit program
 Saving a backup of the circuit program on the hard drive or other media
 Comparing circuit programs
 Easy configuration of blocks
 Transferring the circuit program
– from the xLogic to the PC and
– from the PC to xLogic
 Setting the TOD
 Online test: Display of status changes and process variables of xLogic in
RUN mode:
– Status of a digital I/O, shift register bits and cursor keys
– The values of all analog I/Os
– The results of all blocks
– The current values (including the times) of selected blocks
 Starting and stopping circuit program execution via the PC (RUN,
STOP).
The xLogic alternative
As you can see, xLogic Soft represents an alternative to conventional
engineering methods:
1. You start by developing the circuit program on your desktop.
2. You simulate the circuit program on your computer and verify its functions,
before you actually implement it in your system.
3. You can add comments to the circuit program and create hardcopies.
4. You save a copy of your circuit program to the file system on your PC, to
make it directly available for any modifications.
5. It takes only a few key actions to download the circuit program to xLogic.
