8 SmartWire-DT
8.9 Programming
174 DS7 Soft starter 09/16 MN03901001Z-EN www.eaton.com
8.9.3.6 Profiles 4, 5, 6: Outputs (control)
Output bytes 0 and 1 (Short) are mapped as follows on SmartWire-DT.
Table 33: Profiles 4 to 6: Output bytes 0 and 1
Byte
Bit Designation Meaning
0 0 – Not used
1 - 7 See: Profiles 1, 2, 3: Output byte 0 ￫ section 8.9.3.4,
“Profiles 1, 2, 3: Outputs (control)”
1
(Control
DS7)
0 EN_Set Enable Setpoint, DS7 Start/Stop:
EN_Set enables the setpoint value and starts or stops
the motor with the ramp function.
0: (deactivate setpoint value)
1: (activate setpoint value)
1 – Not used
2 EN_Op Operation released:
0: Stop (immediate disconnection of the output)
1: Operation
3 FaultAck Fault Acknowledge
0: Do not acknowledge current fault
1: Acknowledge current fault (rising edge: 0 → 1)
4 - 7 – Not used
