Page #123 background image
Point Mapping
NOTICE!
Please take into account that the designations of inputs and outputs are set from the
Masters perspective. This way of choosing the designations is due to a de󰊎nition in the
DNP standard. That means for example that Binary Inputs that can be set within the
Device Parameters of the DNP protocol are the “Binary Inputs” of the Master.
Enter the menu [Device Para / DNP / Point map]. Once the general settings of the DNP
protocol are done, the point mapping is to be done as a next step.
Binary Inputs (States to be send to the master)
Double Bit Inputs (Breaker states to be send to the master)
Counters (Counters to be send to the master)
Analog Inputs (e. g. measured values to be send to the master). Please take into
account that 󰊏oating values have to be transmitted as integers. That means they
have to be scaled (multiplied) with a scaling factor in order to bring them into the
integer format.
123www.eaton.comEMR-3MP0
3 Communication Protocols
3.6 DNP3
