Eaton EMR-3MP0 - Slot X2

2.2.7
Slot X2
• Relay Output Card
• SC (Supervision Contact)
Slot3Slot1 Slot2
E_F91
X2 X3
X100
X101
X103
X1
Fig. 12: Rear side of the device (Slots).
The type of card in this slot is dependent on the ordered device type. The di󰊍erent
variants have a di󰊍erent scope of functions.
Available assembly groups in this slot:
• OR3-AnO-Ir: Assembly Group with 2 Normally Open (Form A), 1 Changeover (Form
C), Supervision Contact, Analog Output, IRIG‑B.
