Eaton EMR-3MP0 User Manual

11.1.5
Mechanical Tests
Test Fc: Vibration Response Test
IEC 60068-2-6
IEC 60255-27
IEC 60255-21-1
class 1
(10 Hz – 59 Hz)
Displacement
0.035 mm (0.0014 in.)
(59Hz – 150Hz)
Acceleration
0.5 gn
Number of cycles in each axis 1
Test Fc: Vibration Endurance Test
IEC 60068-2-6
IEC 60255-21-1
class 1
(10 Hz – 150 Hz)
Acceleration
1.0 gn
Number of cycles in each axis 20
Test Ea: Shock Test
IEC 60068-2-27
IEC 60255-27
IEC 60255-21-2
class 1
Shock response test 5 gn, 11 ms, 3 impulses in
each direction
Shock resistance test 15 gn, 11 ms, 3 impulses in
each direction
Test Eb: Shock Endurance Test
IEC 60068-2-29
IEC 60255-21-2
class 1
Shock endurance test 10 gn, 16 ms, 1000 impulses
in each direction
Test Fe: Earthquake Test
IEC 60068-3-3
IEC 60255-27
IEC 60255-21-3
Single axis earthquake vibration test 1 – 9 Hz horizontal: 7.5 mm
(0.295 in.)
1 – 9 Hz vertical: 3.5 mm
(0.137 in.)
1 sweep per axis
259www.eaton.comEMR-3MP0
11 Appendix
11.1 Standards
