2.2.10
Slot X101
• URTD
Slot3Slot1 Slot2
E_F88
X2 X3
X100
X101
X103
X1
Fig. 22: Rear side of the device (Slots).
Depending on the ordered device type, this slot can be equipped with an URTD interface.
NOTICE!
The available combinations can be gathered from the
ordering code.
91www.eaton.comEMR-3MP0
