10 Technical Data EMR-3MP0
NOTICE!
Use copper conductors only, 75°C (167°F).
Conductor size AWG 14 [2.5 mm²].
Climatic and Environmental Data
Storage Temperature: −30°C to +70°C (−22°F to 158°F)
Operating Temperature: −20°C to +60°C (−4°F to 140°F)
Permissible Humidity at Ann. Average: <75% rel. (on 56 days up to 95% rel.)
Permissible Installation Altitude: <2,000 m (6,561.67 ft) above sea level
If 4,000 m (13,123.35 ft) altitude applies, a
changed classi󰊎cation of the operating and test
voltages may be necessary.
Pollution Degree and Equipment Class
Pollution degree: 2
Equipment class: 1
Degree of Protection EN 60529
HMI Front Panel with Seal: IP54
Rear Side Terminals: IP20
Routine Test
Insulation Test Acc. to IEC60255-5: All tests to be carried out against ground and
other input and output circuits.
Aux. Voltage Supply, Digital Inputs, Current
Measuring Inputs, Signal Relay Outputs:
2.5 kV
(e󰊍.) / 50 Hz
Voltage Measuring Inputs: 3.0 kV
(e󰊍.) / 50 Hz
All Wire-Bound Communication Interfaces: 1.5 kV DC
Housing
Housing B1: height / width: 183 mm (7.205 in.) / 141.5 mm (5.571 in.)
