2.2.9
Slot X100: Ethernet Interface
Slot3Slot1 Slot2
E_F93
X2 X3
X100
X101
X103
X1
Fig. 20: Rear side of the device (Slots).
An Ethernet interface may be available depending on the ordered device type.
NOTICE!
The available combinations can be gathered from the
ordering code.
89www.eaton.comEMR-3MP0
