1.2 Information About the Device
What Is Included with the Device
The device package includes all connection terminals, except communication connectors,
but does not include the fastening material. Please check the package for completeness
upon delivery.
Device Package Contents:
1 – Protective Relay;
1 – Mount (Standard or Projection);
1 – Quick Start Guide.
On request, Eaton can provide a data DVD with the following content:
User's Manual, Reference Manual, Wiring Diagrams,
Modbus Register Maps, Pro󰊎bus Register Maps, GSD 󰊎le, IEC 61850 Communication
Documentation,
Device Model for O󰊍-line Parameter Setting
Setup 󰊎les for the PowerPort-E and QualityManager software applications.
NOTICE!
The Device Model
must be installed to allow PowerPort-E to con󰊎gure a device o󰊍-line
(i. e. without the device being connected).
Please make sure the product label, wiring diagram, type code, and materials and
description pertain to this device. If you have any doubts, please contact the Customer
Service Department of Eaton.
Storage
The devices must not be stored outdoors. The storing facilities have to be su󰊐ciently
ventilated and must be dry (see Technical Data, ╚═▷ “Technical Data EMR-3MP0”).
Battery
The purpose of the battery is to bu󰊍er the real-time clock in case of an outage of the
protective device's power supply.
Since it is not used for normal operation of the EMR-3MP0, it is not expected under normal
conditions that a replacement be necessary during the life-time of the EMR-3MP0. If,
however, it happens that the battery needs to be replaced the EMR-3MP0 has to be sent
to the manufacturer as a service request.
20 www.eaton.com EMR-3MP0
