2.2.11.2 Pro󰈌bus DP/ Modbus® RTU via Fiber Optic
RxD TxD
HPT_Z61
Fig. 32: Fiber Optic – FO, ST connector
WARNING!
Do not look directly into the light beam that is emitted from the 󰊎ber optics connector!
Serious injury of the eyes can be consequence of ignoring this warning.
98 www.eaton.com EMR-3MP0
