2.2.10.1 Interface for the URTD Module
The Universal Resistance-Temperature Detector (URTD) module has to be connected to
the protective device at the special 󰊎ber optic interface (1 optical slave).
E_F45
Fig. 23: Interface for the External URTD Module – Terminal Marking
E_F46
RX
Fig. 24: Interface External URTD Module – Terminal Marking
