Slot X3
• CTs (Current Measuring Inputs)
Slot3Slot1 Slot2
E_F92
X2 X3
X100
X101
X103
X1
Fig. 15: Rear side of the device (Slots).
Available assembly groups in this slot:
• TI: Phase and Ground Current Measuring Input Card, standard sensitivity.
• TI‑MP: MP‑3000-compatible Current Measuring Input Card.
