1.2.1
Catalog Codes for the EMR-3MP0
Motor Relay
EMR-3MP0 ‑2 # # # # #
Choose from the following options. ↑ ↑ ↑ ↑ ↑
Hardware Option 1
4 DI, 4 Outputs, Removable Terminals, 1 4…20 mA
Analog Output, URTD interface, IRIG‑B, small display.
A
Hardware Option 2
Standard CT input terminals with shorting block:
Phase Current 1 A / 5 A, Ground Current 1 A / 5 A,
Power Supply Range: 19…300 Vdc, 40…250 Vac.
0
MP‑3000-compatible CT input terminals:
Phase Current 5 A, Ground Current 5 A, Power Supply
Range: 19…300 Vdc, 40…250 Vac.
9
Communication Options (see also ╚═▷
“Communication Protocol Codes”)
No communication protocol A
Modbus RTU + DNP3.0 RTU (RS485 / terminals) B
Modbus TCP + DNP3.0 TCP/UDP (Ethernet 100MB /
RJ45)
C
Pro󰊎bus-DP (Fiber optics interface, ST Connector) D
Pro󰊎bus-DP (RS485 / D-SUB interface) E
Modbus RTU + DNP3.0 RTU (Fiber optic interface, ST
connector)
F
Modbus RTU + DNP3.0 RTU (RS485 / D-SUB interface) G
IEC 61850 + Modbus TCP + DNP3.0 TCP/UDP
(Ethernet 100MB, RJ45)
H
Modbus RTU + DNP3.0 RTU (RS485 /
terminals) + Modbus TCP + DNP3.0 TCP/UDP
(Ethernet 100MB, RJ45)
I
IEC 61850 + Modbus TCP + DNP3.0 TCP/UDP (Fiber
optic interface, LC connector, 100MB)
K
22 www.eaton.com EMR-3MP0
1 EMR‑3MP0 Motor Protection Relay
1.2 Information About the Device
