Main Case Disassembly and Lubrication Tube Removal | Service Procedures TRSM0940
3. Using the K-Line J-hook (RR1004TR), remove the
upper and lower Counter Shafts from the Transmission
Main Case.
Main Drive Gear and Input Shaft Removal
1. Remove the two bolts fastening the Main Feed Tube
assembly to the Transmission Case.
To Next Page
