Main Case Main Shaft Disassembly with Low Force Gearing | Service Procedures TRSM0940
15. Remove the last stepped no-burn washer from the
Main Shaft.
Note: Th
e last or furthest forward no-burn washer is
smaller than the rest. This is specific for the front of the
Main Shaft as the 4th–5th Gear Sliding Clutch is
smaller than the 1st–Reverse and 2nd–3rd Gear Slid-
ing Clutches.
