2018.12.12
© 2017 Eaton. All rights reserved
168
TRSM0940 Service Procedures | Main Case Main Shaft Disassembly with Low Force Gearing
11. Remove the 2nd–3rd Gear Sliding Clutch.
12. Remove the
4th no-burn washer and 3rd Gear.
13. Remove the 5th
flat no-burn washer from the Main
Shaft.
14. Remove
4th Gear (5th for direct drive) from the Main
Shaft.
