TRSM0940 Service Procedures | Main Case Main Shaft Assembly
11. Install the larger reverse washer. Rotate the washer
and push the air line through.
12. Install
the key and push the air line down through the
Main Shaft until it contacts the roll pin.
13. Install the
Reverse Gear on the Main Shaft and slide it
over the sliding clutch with the snap ring groove facing
rearward for installation.
