TRSM0940 Service Procedures | MHP/MXP/VHP/VXP Auxiliary Section Removal and Disassembly
14. Remove the Auxiliary Counter Shaft Bearing Races
from their bores.
15. If necessary, secure
the Countershafts in a vise and
remove both the front and rear bearings from the
shafts with a bearing separator and jaw pullers.
16. Remove the 15/16” cap screw an
d retainer bolt that
was loosened in step 9
17. Remove the splitter gear fro
m the Output Shaft
Note: For disassembly and assembly of
the Splitter
Gear assembly, please refer to the “Splitter Gear Bear-
ing Disassembly and Assembly – MHP,
MXP, VHP,
VXP” section
