EBS-6100 Printer User's Manual
Paragraph 8 - Technical Specifications
EBS
Ink-Jet Systems
®
126
20070529#20.5
two-row,
three-row,
four-row any combination of the above mentioned matrices provided
that the maximum height of vertical rows is 32 dots
;
user-programmable graphics provided that the maximum height of the vertical rows is 32
dots,
bar codes Datalogic, Matrix, 2/5 5 Bars, Interleaved, Code 39, EAN-8,
EAN-13, UPC-A, UPC-A EBS, Code 128, EAN-128,
Code 128B, ITF8, ITF14,
2D code ECC-200 Data Matrix.
8. Terminal
a) Built-in graphic terminal equipped with an alphanumerical keypad and
a graphic LCD display as standard,
b) Personal Computer (optional and independent from the built-in terminal)
• to control the operation of one printer via the EdGraf program, RS-232C
interface, automatic negotiation of 9600 Bd or 19200 Bd transmission rates
(up to 10 m of cable as standard) or RS-485 interface (optional for longer
connections),
• to control a network of EBS printers of various types via the InkNet program,
RS-485 interface at the transmission rate of 19200 Bd.
9. Extra channel V24/RS232C or TTL
(9600 Bd as standard).
10. Conveyor speed converter a shaft-encoder - optionally for unstable
speed conveyors.
11. Operating conditions
a). Non-Pigment ink
b). Power supply
supply voltage AC 100÷240V 45÷440 Hz,
DC 90÷350V;
current 0,5 - 0,27 A - for standard version
compressed air not required (!).
c). Ambient conditions
operating temperature from +5°C to +40°C;
relative humidity up to 90% without condensation.
d). Mechanical exposure
vibration max 1g, max 10 Hz;
shocks max 1g, max 2 ms.
12. Weight about 12,9 kg without ink and
solvent bottles
