PARAMETER DESCRIPTION AND SETTINGS DEFAULT
Spec.reg. :
The so called special register can also be used as a subfile. Its
contents can vary during printing - see section 4.4.1.10 Using
Special Registers.
None, Up counter, Down count., Time, Date,
Spec. chan., Univ.count., Univ. date,
Date+offs., Date+offs.2
None
Front dis :
Leading spacing before a subfile, given as a number of vertical
rows (dots).
0, 1, 2, 3, .... , 5000
0
Back dist :
Leading spacing after a subfile, given as a number of vertical rows
(dots).
0, 1, 2, 3, .... , 5000
0
NOTE:
• While editing a subfile you can modify subfile parameters at any time (by pressing the
§ key).
• While editing a subfile you can change its type at any time (by pressing the
§ key). After the
subfile type has been changed (and possibly subfile parameters modified) and confirmed, the
previous contents of the subfiles are erased.
Subfile Type: Graphics
A GRAPHICS subfile is a block of pixels (on the display) or dots (on an overprint) that are
set/erased separately.
When the
§ key is pressed in the word processor, parameter menu is displayed for your
subfile. The parameters have the following meaning.
PARAMETER DESCRIPTION AND SETTINGS DEFAULT
Type :
Subfile type. Any parameters shown below are typical of a Graphics
subfile.
Graphic
, Barcode, Ins. text, subText
Text
Height :
The maximum height (number of pixels) of a graphics block equals
the maximum height, Hmax, of a printable vertical row.
1, 2, 3, .... , Hmax
Hmax
Length :
Expected length (number of pixels) of a graphics block.
1, 2, 3, .... , 32767
the same
as the
height
setting
Front dis :
Blank space (number of vertical rows) before a graphics block.
0, 1, 2, 3, .... , 5000
0
Back dist :
Blank space (number of vertical rows) after a graphics block.
0, 1, 2, 3, .... , 5000
0
!
