EBS
Ink-Jet Systems
®
EBS-6100 Printer User's Manual
Paragraph 5 - Examples of How to Operate the Printe
20070529#20.5
97
Use terminal keys to type in text COFFEE, which is then stored in the printer’s
memory after it has been confirmed with the
V key.
7) Set print parameters.
All options are normally preset by the Manufacturer to meet user requirements. Print
parameters are set to their default
7
settings. The only important thing in making print is
the source of timing pulses: a shaft-encoder (travel speed indicator) or an internal
generator. If the head is set to work with the shaft-encoder, it will make overprints only
when the shaft-encoder axle rotates.
If the head is set to work with the internal generator, the overprints are made at a fixed
rate no matter how fast the objects move (even if the object does not move). The option
can be modified with the Generator print parameter and either GENerator or SHAFT-
encoder can be set.
In the main MENU select the PRINTING item,
and then the PRINTING PARAMETERS
item.
For how to modify print parameters see section 4.4.3.5 Print Parameters.
The parameters should be set to the following values:
Vert. direct. : UP
Space : 2,0 mm
Text rpt. : 1
Rpt.dist. : 30,0 mm
Direction : LEFT
Height : LARGE
Offset : 1
Offset2 : 1
Counter delta : 1
Row repetit. : 1
Mode : NORMAL
Speed : SLOW
Interleave : STANDARD
Generator : !!!see above!!!
Resol. dot/cm : 30
Cnv spd m/min : 10,0 only for Generator=GEN or
Enc const p/m : 10000 only for Generator=SHAFT.
8) Start printing the text file TXT1 you have just created.
In the main MENU select the PRINTING item,
and then the START PRINT item.
Printing starts after the name TXT1 has been typed in and confirmed.
If you want to stop the printing, select the STOP PRINTING command from the
PRINTING submenu.
NOTES:
The START PRINT command is followed by the application of high voltage (the green
lamp PRINT ON/OFF on the main pad of the external panel and the red lamp HV ON on
the internal panel
emit a steady light) and an overprint is made each time the photo
detector is activated. Therefore place a product or sheet of paper in front of the head at
a distance smaller than 20 mm (to get good quality prints). The proper operation of the
photo detector is indicated by a red LED indicator at the back of the photo detector. If
a product has been detected, the lamp goes out. While conducting print tests cover the
photo detector with your hand for a while to release its operation.
7
Default value – a preliminary value defined by the Manufacturer.
!
