Kraftformer KF 170 PD
2018-05-09 | ECKOLD AG 10
Technical data
2.6 Painting
Apparatus head
light blue , RAL 5012
textured coating (without silicon)
Pedestal
sapphire , RAL 5003
textured coating (without silicon)
2.7 Ambient temperature range
Operating ambient temperature -20°C ..... +55°C
Storage and transport temperature -25°C ..... +70°C
2.5.3 Working stroke
Adjustable stroke length 2 - 6 mm (by adjusting handle)
Steps of stroke length 0.05 mm
+/- 0.05 mm
2.5.2 Ram postion
Area of the ram adjustment 8 mm (by Handwheel)
Steps of the ram adjustment 0.1 mm
+/- 0.1 mm
