Kraftformer KF 170 PD
2018-05-09 | ECKOLD AG 8
Technical data
2.3.2 Forming capacity of the Kraftformer KF 170 PD
Mild steel 400 N/mm
2
2,0 mm
Stainless steel 600 N/mm
2
1,5 mm
Aluminium 250 N/mm
2
2,0 mm
Copper 250 N/mm
2
2,0 mm
2.3 Short Description
2.4 Drive
Drive air
Release Pedal
Working pressure max. 60 kN
Input pressure ~ 6 bar (87 psi)
Air consumption in continuous mode max 300 l/min.
Stroke frequency (dep. on setting) in
continuous mode
~150 - 250/min.
The air operated KF 170 PD is the smallest of the ECKOLD Kraftformer machines. It can be switched to sin-
gle or continuous stroke and can form mild steel material up to 2.0 mm thickness. The single stroke operati-
on makes the KF 170 PD ideal for correcting and adjusting jobs – and it can be used for punching, notching
and clinching (connecting of sheet metal and profile sections).
Please take into account the maximum forming capacity of each tool in the accompanying tool
catalogue.
2.3.1 Purpose of use
The machine ECKOLD Kraftformer type KF 170 PD is to be used for cold forming of sheet metal and profile
sections up to the max. plate thickness mentionned under item 2.3.1.
Do not use the KF 170 PD Kraftformer machine for any other purpose!
Original ECKOLD forming tools are available for reforming work.
Use only original ECKOLD forming tools!
The machine must NOT be used or modified for other work!
