Eckold KF 170 PD - Eccentric Lever Parts

Kraftformer KF 170 PD
2018-05-09 | ECKOLD AG MEL-6
Machine Spare Parts List (MEL)
Pos Item No. Designation Qty Type / Dimensions
023.125.0004 Eccentric lever
1 023.910.0176 Eccentric shaft 1
2 260.009.0064 Clamping lever with threaded bolt 1 MR. 63 p-M 8x16
3 258.270.0026 Tension disc, light 1 M 8 d 18/8.4 x 1
4 258.340.0007 Safety-ring for shaft bl. st. 1 DIN 471 d 10
5 023.910.0316 Tension piece 1
6 023.910.0275 Covering 1
11.3.3 Eccentric lever 023.125.0004
