49
Kraftformer KF 170 PD
2018-05-09 | ECKOLD AG
8.4.3.2 Lubrication instruction
• Lubricate the product according to the following table.
• Observe the lubrication directives exactly to avoid a premature erosion of the ball bearings
• Use only the given lubricants or ones of the same quality. The grease gun delivered with
the machine is filled with this grease.
All lubrication points have been provided with sufficient lubricant by the manufacturer. Therfore, no lubri-
cation is necessary when putting the machine into service.
No. Contact position: A B
Sign of the
contact:
Lubrication h:
- apply one stroke of the grease gun after approx. 50'000 strokes
(equals approx. 24h non stop use)
Lubricant: Molykote TP42
Capacity: 1x (press firmly)
B
A
WARNING
— Unintentional starting of the product
—> Risk of injury to personnel and damage to the product
• Always turn the air supply before attempting any repairs or service work.
Maintenance
