7.7.1 Recommended Settings for Ram position and Stroke length
Tools Ram postion Stroke length setting
Material:
1.0 mm mild steel (R
m
~400 N/mm
2
)
Ram postion Stroke length setting
FWA 405 K 5.5 2.8
FWA 602 K 6.5 2.8
FWR 407 K 5.5 2.8
FWR 603 K 6.5 3.0
HS 40 K 6.0 2.8
Tools Ram postion Stroke length setting
Material:
1.0 mm aluminium not hardened,
formable (R
m
~250 N/mm
2
)
Ram postion Stroke length setting
Material: ...................................................
Material: ...................................................
HFL 70 K 6.0 3.0
i INFO
(unbinding, best setting to be determined by try-out)
