Kraftformer KF 170 PD
2018-05-09 | ECKOLD AG 28
5.5.2 Foot switch for single- or continuous stroke
Single stroke
position
Continuous stroke
position
iIMPORTANT
The tools ASW 42 K (Notching tool), LSW1K (Punching tool) and DFW 1 K (Clinching
tool) must only operated in single stroke mode! Otherwise tools will be damaged or
even destroyed!
Construction and Operation
