4.8.3 Swivelling up of Apparatus head
2. Have two persons swivel up the Apparatus head.
1. Remove transport security profiles.
Pic. 4.8.3b - Swivelling up of Apparatus head
WARNING
— Overestimation of your own body strength
—> Damage to health, damage on the product and tools
• Two persons are required to swivel up the Apparatus head
1.1
1.2
2.1
Pic. 4.8.3a - Remove transport security profiles.
