MEL-13
Kraftformer KF 170 PD
2018-05-09 | ECKOLD AG
Machine Spare Parts List (MEL)
Pos Item No. Designation Qty Type / Dimensions
023.125.0001 Pneumatic cylinder
1 023.910.0273 Bolt 2
2 023.910.0274 Washer 2
3 023.910.0272 Flexible mounting block 1
4 023.910.0271 Flange 1
5 023.125.0025 Piston 1
6 023.910.0163 Cylinder tube 1
7 023.910.0160 Flange 1
8 023.910.0164 Piston rod 1
9 023.910.0162 Guiding pipe 1
10 254.027.0020 Articulatet head 1 Durbal BEF D 14-H7
11 265.021.6051 Guiding ring 1 BS 50702-0200-C-10 D 20 mm
12 021.400.1004 Pressure spring 1 Dm 32 x d 3.5x Lo 230
13 258.340.0037 Safety-ring for shaft 1 DIN 471 d 45
14 252.000.0425 Cap screw 4 DIN 912 M 8x120
15 265.021.5030 O-ring seal 1 0352-8307 D123.19x5.33
16 265.021.6705 Guiding ring 1 BS 50702-1400-A-10 d 140 mm
17 265.022.0122 Turcon glyd ring 1 PPT 0301400-280 / D140.0x5.9x3.45
18 265.021.5060 O-ring seal 1 0160-8307 D133.0x2.62
19 252.000.0319 Cap screw 2 DIN 912 M 6x70
20 277.000.1010 L-type plug connection 1 QSLV-1/4-10
21 277.002.0108 Synthetic hose 1 PUN-10 x 1.5 x 420 lang
22 277.000.2112 Reducing nipple with sealing ring 1 Bosch G1/2 - G1/4
23 277.000.0416 Reducing nipple with sealing ring 1 D - 3/8 i - 1/2 a
24 277.003.1902 Quick air relief cock 1 NG 12-G1/2"
25 277.003.0410 Muffler 1 G 3/8"
26 252.000.0407 Cap screw 1 DIN 912 M 8x25
27 023.910.0317 Clamp 1
28 266.011.0895 Pressure spring 1 Dm 8 x d 0.8 x Lo 68
29 277.000.4118 Sealing ring 1 G 1/2"
