MEL-19
Kraftformer KF 170 PD
2018-05-09 | ECKOLD AG
Machine Spare Parts List (MEL)
Pos Item No. Designation Qty Type / Dimensions
021.300.2029 Continuous stroke modul
1 021.400.2087 Washer 1
2 021.400.2088 Plate 1
3 021.400.2089 Mounting bracket 1
4 021.400.2090 Threaded plate 2
5 256.021.0909 Hex socket set screws with flat point 3 DIN 913, M 5 x 20
6 252.000.0207 Socket head cap screw 1 DIN 912, M 5 x 20
7 252.000.0201 Socket head cap screw 2 DIN 912, M 5 x 8
8 252.000.0108 Socket head cap screw 4 DIN 912, M 4 x 20
9 277.003.2512 Pneumatic - Impulse valve 1 FESTO J-5-1/4-B
10 275.010.3215 Three-way ball valve 1 0448 06 13 G 1/4, DN 6
11 277.003.3310 Valve 2 FESTO R/O-3-PK-3
12 277.000.1632 T-hose connection 1 FESTO T-PK-3
13 277.000.1010 L - Push-in fitting 1 FESTO QSLV-1/4-10
14 277.000.0370 Push-in fitting 2 FESTO QS-1/4-10
15 277.000.0910 L - Push-in fitting 1 FESTO QSLL-1/4-10
16 277.000.2320 Quick connector 3 FESTO CK-1/8-PK-3
17 277.000.0514 Blanking plug 1 FESTO B - 1/4
18 277.001.0054 Muffler 2 FESTO U - 1/4
19 277.000.2835 T - Push-in fitting 1 FESTO QSTL-1/4-10
20 277.000.2915 Reducing sleeve 1 FESTO QMR-1/4-1/8-B
21 277.000.4335 T - Push-in fitting 1 FESTO QST - G 1/4 - 10
22 252.000.0212 Socket head cap screw 2 DIN 912, M 5 x 40
23 258.000.0015 Flat washer 2 DIN 125 A, M 5
24 271.501.0605 Cable grommet 1 B 13 mm / C 17.5 mm / D 4 mm
25 021.400.2110 Designation ”Single or Continuous stroke” 1
26 277.002.0072 Plastic tubing 1 FESTO PU - 3 / 100 mm
27 277.002.0072 Plastic tubing 1 FESTO PU - 3 / 100 mm
28 277.002.0072 Plastic tubing 1 FESTO PU - 3 / 520 mm
29 277.002.0072 Plastic tubing 1 FESTO PU - 3 / 700 mm
30 277.002.0072 Plastic tubing 1 FESTO PU - 3 / 600 mm
31 277.002.0108 Plastic tubing 1 FESTO PUN - 10x1,5 - 3 / 110 mm
32 277.002.0108 Plastic tubing 1 FESTO PUN - 10x1,5 - 3 / 300 mm
33 277.002.0108 Plastic tubing 1 FESTO PUN - 10x1,5 - 3 / 65 mm
34 277.002.0108 Plastic tubing 1 FESTO PUN - 10x1,5 - 3 / 50 mm
021.400.2091 Pneumatic diagram 1
