12
II-3. Repeater Mode
When you set the operation mode to repeater mode, the AP will not get an IP
address from the router/root AP. You will need to set your computer’s IP
address and use the APs default IP address to access the UI for the first time,
refer to Appendix for more help.
Wireless Settings Wireless Extender displays details about the APs wireless
connection in repeater mode and enables you to connect to a source SSID and
configure the new (repeater) SSID. Settings are saved as profiles.
1. Set your computer’s IP address to 192.168.2.x where x is a number in the
range 3 – 100.
Please ensure there are no other active network connections on
your computer (disconnect Wi-Fi connections and Ethernet
cables).
2. Enter the access point’s default IP address 192.168.2.2 into the URL bar of
a web browser.
3. You will be prompted for a user name and password. Enter the default
username “admin” and the default password “1234”.
