Edimax CAP1750 User Manual

Edimax Pro NMS
196
RADIUS Type
Select “Internal” to use the access point’s
built-in RADIUS server or “external” to use an
external RADIUS server.
RADIUS Server
Enter the RADIUS server host IP address.
Authentication
Port
Set the UDP port used in the authentication
protocol of the RADIUS server. Value must be
between 1 – 65535.
Shared Secret
Enter a shared secret/password between 1 –
99 characters in length. This should match the
“MAC-RADIUS” password used in IV-3-1-3-6 or
IV-3-2-3.
Session Timeout
Set a duration of session timeout in seconds
between 0 – 86400.
Accounting
Enable or disable RADIUS accounting.
Accounting Port
When accounting is enabled (above), set the
UDP port used in the accounting protocol of
the RADIUS server. Value must be between 1 –
65535.
IV-6-5-2. Internal Server
The access point features a built-in RADIUS server which can be configured as
shown below used when “Internal” is selected for “RADIUS Type” in the “Local
Network”  “RADIUS Settings” menu.
To use RADIUS servers, go to “Wireless Settings”  “Security”
“Additional Authentication” and select “MAC RADIUS
Authentication” (see IV-6-2-3. & IV-6-3-3).
