Edimax CAP1750 User Manual

Edimax Pro NMS
174
IV-6-1-3. VLAN
The “VLAN” (Virtual Local Area Network) page enables you to configure VLAN
settings. A VLAN is a local area network which maps workstations virtually
instead of physically and allows you to group together or isolate users from
each other. VLAN IDs 1 – 4095 are supported.
VLAN IDs in the range 1 – 4095 are supported.
VLAN Interface
Wired LAN Port
Identifies LAN port. USB is the LAN port
attached via mini USB adapter.
VLAN Mode
Select “Tagged Port” or “Untagged Port” for
specified LAN interface.
VLAN ID
Set a VLAN ID for specified interface, if
“Untagged Port” is selected.
Management VLAN
VLAN ID
Specify the VLAN ID of the management VLAN.
Only the hosts belonging to the same VLAN can
manage the device.
